RTK Heading GNSS Receiver | TQ-NC305
TQ-NC305 RTK GNSS Positioning & Heading Receiver
Industrial dual‑antenna RTK heading GNSS receivers with 20 Hz update rate, built‑in 4G & IP65 protection
TQ‑NC305 receiver is a new‑generation satellite positioning and heading receiver developed based on self‑developed high‑precision GNSS chip. It supports multi‑system full‑frequency‑band signals and realizes 20 Hz RTK positioning and dual‑antenna heading calculation. Equipped with built‑in 4G module, embedded Ntrip protocol and cloud‑chip integrated SDK, it supports standalone RTK, remote OTA and remote control. Featuring ultra‑compact size and high integration, it targets various high‑precision positioning & heading scenarios for unmanned vehicles, small‑size AGVs, UAVs, USVs, intelligent driving and precision agriculture.
TQ-NC305 RTK Heading GNSS Receiver
Key Features:
- Adopt self-developed multi-system full-band GNSS chip
- Support multi-constellation & multi-frequency signals with configurable frequency combinations: BDS B1I,B3I,B2a; GPS L1C/A,L2P(Y)/L2C,L5; GLONASS G1,G2; Galileo E1,E5a,E5b; QZSS L1C/B,L2C,L5; SBAS L1C/A
- Real-time 20 Hz RTK positioning plus dual-antenna heading solution
- IP65 protection rating, 1.2 m drop resistance
- Rich interfaces: RS232 serial port and 4G for data communication
- Built-in 4G, Ntrip protocol and cloud-chip integrated SDK for one-click RTK; support remote OTA and remote control
Overview
Specifications
Applications
- Unmanned Aerial Vehicle (UAV)
- Unmanned Surface Vehicle (USV)
- Cleaning Robot
- Autonomous Logistics Vehicle
- Small‑size AGV
- Intelligent Driving
- Precision Agriculture
